| Lifting Capacity(T) | 1-5 | 10 | 16 | 20 | ||||
| Span(m) | 7.5-30 | 7.5-30 | 7.5-30 | 7.5-20 | ||||
| Crane travel Mechanism | travel speed(m/min) | 20 (Gound) | 30 (Cab) | 20 (Gound) | 30 (Cab) | 20 (Gound) | 20 (Gound) | |
| speed ratio | 58.78 | 39.38 | 58.78 | 39.38 | 58.78 | 58.78 | ||
| motor | power(kw) | 2*0.8/4*0.8 | 2*1.5 | 2*1.5/4*0.8 | 2*1.5 | 2*1.5/4*1.5 | 4*1.5 | |
| rotation speed(n/min) | 1380 | 7.5-22.5/22.5-31.5 | 7.5-22.5 | 7.5-14/14-19.5 | 7.5-31.5 | |||
| Electric Hoist | Electric hoist | single speed | double speed | single speed | double speed | single/double speed | single/double speed | |
| Lifting speed(m/min) | 8 | 8/0.8 | 7 | 7/0.7 | 3.5 | 3.5 | ||
| Cross speed(m/min) | 20 | 20 | 20 | 20 | ||||
| Motor | cone squirrel-cage model | cone squirrel-cage model | cone squirrel-cage model | cone squirrel-cage model | ||||
| working class | A3 A4 A5 | A3 A4 A5 | A3 A4 A5 | A3 A4 A5 | ||||
| Power voltage | 380V-690V | 380V-690V | 380V-690V | 380V-690V | ||||
| wheel diameter(mm) | Φ270 | Φ270 | Φ270 | Φ270 | ||||
| Rail width | 37-70mm | 37-70mm | 51-70mm | 51-70mm | ||||
