| Lifting Capacity(T) | 0.5 | 2 | 3 | 5 | 10 | ||
| Span(m) | 1-18 | 1-18 | 1-18 | 1-18 | 1-18 | ||
| Crane travel Mechanism | travel speed(m/min) | 20/30 | 20/30 | 20/30 | 20/30 | 20/30 | |
| motor | power(kw) | 0.4*2 | 0.4*2 | 0.4*2 | 0.4*2 | 0.8*2 | |
| rotation speed(n/min) | 1380 | 1380 | 1380 | 1380 | 1380 | ||
| Electric Hoist | Electric hoist | double speed | double speed | double speed | single/double speed | single/double speed | |
| Lifting speed(m/min) | 8/0.8 | 8/0.8 | 8/0.8 | 8/0.8 | 3.5 | ||
| Cross speed(m/min) | 20/30 | 20/30 | 20/30 | 20/30 | 20 | ||
| Motor | cone squirrel-cage model | cone squirrel-cage model | cone squirrel-cage model | cone squirrel-cage model | cone squirrel-cage model | ||
| Working class | A3 A4 A5 | A3 A4 A5 | A3 A4 A5 | A3 A4 A5 | A3 A4 A5 | ||
| Power voltage | 380V-690V 3 phase 50 Hz | 380V-690V 3 phase 50 Hz | 380V-690V 3 phase 50 Hz | 380V-690V 3 phase 50 Hz | 380V-690V 3 phase 50 Hz | ||
| Wheel diameter(mm) | 130 | 130 | 130 | 150 | |||
| Rail | 120a-145c | I 32a-I 45C | I 32a-I 45C | I 40b-I 63C | |||
